High Voltage 12KV Three Phase SF6 Gas Insulated Load Break Switch

Message

$1,300.00

Have chosenThere are no options selected.

Start To Order

Add To Cart Successfully!

High Voltage 12KV Three Phase SF6 Gas Insulated Load Break Switch
High Voltage 12KV Three Phase SF6 Gas Insulated Load Break Switch
High Voltage 12KV Three Phase SF6 Gas Insulated Load Break Switch
High Voltage 12KV Three Phase SF6 Gas Insulated Load Break Switch

High Voltage 12KV Three Phase SF6 Gas Insulated Load Break Switch

  • Item No.FZW28-12F
    MOQ10 Piece
Tag  sourcing

Quantity:

From $ 1300.00  / Piece
$ 13,000.00
You save  $  -13,000.00
Trade Assurance protects your orders
On-time Dispatch Guarantee
On-time dispatch is guaranteed or you will be eligible to claim platform compensation.
Refund Policy
If the shipment is delayed or product quality differs from what are specified in the online order, you can claim for a refund.
Quick refund: If you can apply for a refund within two hours of making a payment, you will receive a refund immediately.

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Quick Details
Place of OriginCN;ZHE
Brand NameJecsany
Model NumberFZW28-12F
Materialstainless steel or hot-dip galvanized steel.
MOQ10
TypeVacuum Load Switch
Product NameVacuum Load Switch
altitude≤1000m
ambient temperature-40°C-+45°C
Wind speed35m/s
Product Description




       Users boundaries FZW28-12F Outdoor vacuum load switch (FFK), rated voltage 12kV, three-phase AC 50Hz outdoor column distribution switchgear. Vacuum interrupter and SF6 gas against ground.interphase dielectric, is a maintenance-free load switch.

      This product complies with: GB3804 "AC high voltage load switch" and GBT11022 "high-voltage switchgear and control equipment standard common technical requirements." The boundaries of outdoor vacuum load switch (negative dutch switch body and FDR-01-type fault detection Contrllr) with fault detection, protection and control functions and communication functions, mounted on responsibility 10kV distribution line at the demarcation point into the line user, you can also applicable to meet the requirements of the branch line connection in conjunction with the pre-coincidence, automatic removal of single-phase ground fault isolation and automatic phase short circuit fault, and can quickly locate the point of failure.






Model description


 Technical Parameter

Name UnitData
Rated voltagekV12
Rated frequencyHz50
Rated currentA630
Active load breaking current / frequencyA/Secondary630A/≥100
Rated peak withstand currentKA50
Rated short time withstand currentKA20
Rated short circuit making current (Peak)KA50
Mechanical enduranceSecondary≥10000
Rated duration of short circuit withstandS4

Rated power frequency

withstand voltage (1min)

White, relativelyDry test, wet test  KV 42/34
 Fracture Dry test 48

 Rated lightning impulse

withstand voltage

 White, relatively KV 75/85
 Fracture
 Rated control voltage V 220


Standard

1.GB3804 "AC high voltage load switch"

2.GBT11022 "high-voltage switchgear and control equipment standard common technical requirements."



Ambient condition

1. The maximum ambient air temperature does not exceed 40C, not limited to not more than -45C;

2. The wind speed is not greater than 35m/s;

3. alitude higher than 1000m, the earthquake intensity does not exceed 8 degrees;

4. Humidity: monthly average relative humidity less than 90%; daily average relative humidity less than 95%;

5. ice thickNess does not exceed 10mm;

6. The installation site should be non-flammable, explosive, chemical corrosion and recurrent severe vibration place; .

7. Neutral Grounding Mode: ungrounded neutral point arc suppression coil grounded neutral grounding via low resistance.
